7
OPERATOR MANUAL HCS-5 020310 5.7.x 03
GENERAL OVERVIEW
Interceptors
The interceptor creates pressure on the hull bottom plate directly
ahead of the transom using a blade. With only a few millimeters,
the transom edge raises and results in a high hydrodynamic lift. The
interceptor provides forces to optimize running trim and actively
dampen vessel motions.
Fins
As the vessel speeds through the water, the water moves along the n body. If the n is given an angle of attack, the
n creates a lifting force acting on the vessel to reduce vessel motions.
To reduce roll motion when the vessel is stationary or moving at speeds below 4 knots, the ns do a strong paddle
to counteract each wave induced roll motion which result in reduced roll motions onboard the vessel.
Example of Placement
Fins
Interceptors
RCU
Control Panel
