Uninstalling the Light Fixture
To uninstall the light xture, rst disconnect the plug connectors
between the black wire and the black/white wire.
Disconnect the plug connectors between the two white
Uninstall the nut and washer from the end of the light
xture inside the lower switch housing.
Unscrew the threaded rod of the light xture from the
Remove the light xture from the lower switch housing
pulling disconnected wires through the hole in the center
of the lower switch housing.
When removing the wires, pull the thin plug
connector (male) through rst, and then pull the other
plug connector (female) through the hole.
Install the dummy terminals (included in the sack parts)
on the two disconnected wires in the lower switch
Install the switch housing cap and plug button to the
Continue with step 7-6 on page 12.
