5 • Installing the Canopy and Canopy Trim Ring
Failure to complete the following steps could cause the fan
It is recommended you use a magnetic tip screwdriver for the
Rotate the hanger ball so the tab in the canopy is secure in the
Your fan may have multiple tabs and
grooves that must be aligned.
Swing the fan up to align the canopy screw holes with the
mounting holes on the ceiling plate.
e slots in the canopy must remain engaged while
swinging the canopy for alignment.
Holding the canopy up with the screw holes aligned, partially
install two canopy screws into the holes opposite the ceiling plate
Partially install a canopy screw between the slots in the canopy.
When all the holes are properly aligned, securely tighten all three
Verify that the tabs in the canopy are still in the grooves of the
Align the tabs on the trim ring opposite the grooves in the hanger
ball. Using both hands, push the canopy trim ring up to the top of
the canopy. e canopy trim ring will snap and lock into place.
Should you need to remove the trim ring, press rmly on
opposite sides of the trim ring directly above the groove in the
hanger ball. e tabs will ex out releasing the canopy trim ring.
To Next Page
