Fan may fall if not assembled as directed in these
installation instructions.
Unbundle the wires from the fan.
For Standard or Angle mounting:
Insert the downrod through the canopy and canopy trim ring.
Feed the wires from the fan through the downrod on one side of
Loosen the square head set screw on the adapter to install the
When the pipe and ball assembly
is fully installed, 2-3 threads on the pipe will still be visible; this is
normal. Securely retighten the set screw with a wrench or pliers.
4 • Hanging and Wiring the Fan
e adapter has a special coating on the threads. Do
not remove this coating; the coating prevents the downrod from
unscrewing. Once assembled, do not remove the downrod.
For Low Pro le mounting:
For low pro le mounting, the downrod is replaced with the
Remove the set screw from the adapter.
Place the low pro le washer into the canopy with the lip down.
Align the holes in the washer with the holes in the adapter.
Assemble securely with three low pro le screws.
4 • Hanging and Wiring the Fan
Standard or Angle Mounting
To Next Page
