4 • Hanging and Wiring the Fan
Raise the fan and align the slots in the canopy with the hooks on the
To hang the fan, you must tilt the canopy to an almost vertical
position so that the canopy slots sit on the ceiling plate hooks.
All wiring must be in accordance with national and local electrical
codes and ANSI/NFPA 70. If you are unfamiliar with wiring, use a
Wall switches are not included. Select an acceptable general-use switch in
accordance with national and local electrical codes.
Make sure the power to the outlet box and associated wall switch
To connect the wires, hold the bare metal leads together and place a
wire nut over them, then twist the wire nut clockwise until tight.
Be sure no bare wire or wire strands are visible after
If you want to, you can control both fan and light with one switch. To
do so connect the wires as follows:
e bare or green ground wire from the ceiling to the green
ground wire from the ceiling plate and the green ground wire
e white wire from the ceiling to the white wire from the fan
e black wire from the ceiling to the black and the black/white
e bare or green ground wire from the ceiling to the green
ground wire from the pipe ball assembly
e white wire from the ceiling to the white wire from the fan
e black wire from the ceiling to the black wire from the fan
e black/white wire from the fan to the wire for the wall switch
Push all wires and wire nuts into the outlet box.
To Next Page
