Installing the Glass Bowl
1.
First install the included bulb. Connect the plug connector from the bulb
to the light kit.
2.
Attach the extra pull chain (included) to the fan pull chain using the
plastic breakaway connector. (You may  nd the plastic breakaway
connector on the end of the extra chain.)
3.
 read the fan pull chain through the hole in the metal disk.  en, thread
the fan pull chain through the hole in the center of the glass bowl.
4.
 read the light pull chain through the hole in the center of the glass
bowl.
5.
Place the cover plate up against the glass bowl. Align the holes in the cover
plate and glass bowl.
6.
 read the fan pull chain and
light pull chain through the
appropriate holes.
7.
 read the light pull chain
through the  nial and screw
the  nial onto the threaded
rod end until tight.
Light Bulb
Metal Rod
Metal Disk
Glass Bowl
Cover Plate
Finial
Breakaway
Connector
