www.HunterFan.com
1.888.830.1326
12
M0096-01 • 04/23/14 • © Hunter Fan Company
Install three blade assembly screws,
found in the hardware bag.
Note: In order to provide proper blade
support, choose the three screw holes
that are aligned with the three arms of the
blade ring as shown in the illustration.
Lift a blade ring to the motor assembly
and align the screw holes.
If you wish to install your fan with
three blades, skip to the next page.
If you wish to install your fan with six
blades, lift the optional second blade
ring to the motor assembly and
install three blade assembly screws,
found in the hardware bag, as
shown in the illustration.
Blades
Screw
Holes
To Next Page
