Hunter OSCILLATING 90405 - Operation; Off; Speed Selection; Oscillation Control; Fan Angle Adjustment

11
©2010 Hunter Fan Co. 44086-01 20101102
Figure 19.
High
Medium
Low
Off
Figure 20.
Figure 21.
OPERATION
To turn the fan on and off / control the speed. Turn the
speed knob on the top of the motor to the porper setting.
Figure 19.
Off / Speed Selection
Oscillation
To allow the fan to oscillate, push the Knob beside the fan
speed control down. Pull up on the knob if oscillation is
not desired. Figure 20.
Adjustment
To adjust the angle the fan is blowing.
1. Loosen the adjustment knob under the Fan Motor
2. Adjust the fan to the angle desired and retighten the
knob to secure the fan at that angle. Figure 21.
When adjusting the height of the fan, always grip the
pole above the adjustment knob firmly to prevent the
telescoping pole from collapsing.
