Do not discard the hardware bags or mix parts from
different bags. Make note of the symbol printed on
each hardware bag. The symbols can be used to
identify the appropriate hardware for each step.
x4
x15
x5
x15
x2
x2
For installing the hanger bracket and wiring the fan
For installing the blades
For installing the canopy
For installing the light xture
bag
bag bag
Hunter Pro Tip:
Find a part that is missing or damaged?
Don’t take it back to the store. Let us make it right. Visit us at HunterFan.com or call us at 1.888.830.1326.
Spare Parts
For your convenience,
you may receive extra fasteners.
bag
Glass
Switch Housing Plate
Light Kit Assembly
Motor
Trim Ring
Canopy
Top Housing
Blade Screw
BladeWasher
Blade
Ceiling Bracket
Wood Screw
WIre Nut
Washer
M3735-01 r040220
We recommend that you pull everything out of the box and lay it out. We have
grouped the drawn components below with the hardware you’ll need for those
parts. The screws below are drawn to scale to make it easier to identify what
piece of hardware is needed to install each component.
Here is what comes in your box:
x2
Bulb
x3
x1
x3
Top Housing
Screw
Grounding
Screw
bag
x6
Switch
Housing Screw
Light Kit
Screw
x3 x3
bag
Canopy
Screws
Remote Components
Remote Control
Remote Receiver
Remote Cradle
Fan style may vary.
Note:
