41951-01 12/01/2013
12
C17
C18
C19
C20
C15 C16
Drill a hole in the center of each outline. Insert screws, leaving space between the screw head
and the joist. Screws are not provided.
Attach the rails onto the screws. Tighten screws.
Connect 4” duct and vent to the outside. Tape joints.
If ducting does not fit securely, an adapter may
need to be purchased.
Route wires through the strain relief. For supply connection,
use wires suitable for at least 90º C (194º F).
To Next Page
