Hunter Sona - Installation: New Construction - Final Assembly and Testing; Wiring Harness Connection; Motor Reinstallation and Securing; Power On and Motor Test

41951-01 12/01/2013
7
A19
J
A20
0000
A17
0000
I
A18
ON
OFF
A21 A22
E1
Go to step
on page 17
to attach grille.
Secure the motor by tightening the 2 screws. Turn on the power source.
Connect wiring harness. DO NOT ALLOW THE MOTOR TO
HANG FROM THE WIRING HARNESS.
Reinstall the motor by inserting the tabs and pushing up
into position. Make sure the wires are not pinched between
the motor and the housing.
Test the motor. If the motor does not run,
check the plug connection.
