Hunter Sona - Installation: Suspended Between Joists - Rail Mounting; Mounting Rail Insertion; Depth Mark and Hole Marking; Drilling and Screw Insertion

41951-01 12/01/2013
8
Slide the mounting rails into brackets.
Mark position of screws by using holes as a template.
Insert screws, leaving space between the screw
head and the joist. Screws are not provided.
New Construction – suspended between joists
B11
E
F
5/8
1/2
5/8
1/2
B12
1/8” bit
B14
B15
B16
F
B13
Position the correct depth mark at the bottom edge of
the joist based on the thickness of your sheetrock.
Drill a hole in the center of each outline.
Attach the rails onto the screws.
