8
45066-01 • 03/03/10 • Hunter Fan Company
3-1. To assemble the housing to the hanger adapter, align the three
raised tabs on the hanger adapter with the three narrow notches
in the top housing. Make certain the housing sits at on the
adapter.
3-2. Install three (3) assembly screws and washers and tighten them
securely.
Steps 3-1 – 3-2
Top
Housing
Assembly Screw
Washer
Hanger Adapter
3 • Assembling the Top Housing
