HunterDouglas PowerView+ Automation - Schematic

GETTING STARTED
5
Schematic
WARNING: Do not place more than two 16 Shade Smart Power Supplies
on a single home circuit with a 15 amp breaker.
16 AWG
16 AWG
OUTPUT: 18V DC
(97.5W)
HDR-100-15N
POWER SUPPLY
CLASS 2
INPUT: 120V AC
3A
OUTPUT: 18V DC
(97.5W)
HDR-100-15N
POWER SUPPLY
CLASS 2
INPUT: 120V AC
3A
OUTPUT: 5V DC
(12W)
HDR-15-5
POWER SUPPLY
CLASS 2
INPUT: 120V AC
0.5A
L N
+
-
L N
+
-
LN
+
-
Shade
-
- -
- -
- -
- -
- -
- -
- -
Shade Shade Shade Shade Shade Shade Shade Shade Shade Shade Shade Shade Shade Shade Shade
Shade Communications
Ethernet
D+ D+
D-
++
-
D-
D+
D-
+
D+
D-
+
D+
D-
+
D+
D-
+
D+
D-
+
D+
D-
+
D+
D-
+
D+
D-
+
D+
D-
+
D+
D-
+
D+
D-
+
D+
D-
+
D+
D-
+
D+
D-
+
16 Shade Smart Po
wer Supply
PCN: 1014232
Input: 120V AC ~60Hz, 6.5A
Output: 18V DC 207W
5 FLA Total
Max Operating Temp 50°C
Indoor Use Only
CAUTION:
When daisy-chaining
shades, the connections
to the terminal blocks
at the power supply must
be distributed properly.
A maximum of three shades
can be connected to one
terminal block. A maximum
of eight shades is allowed
per HDR-100-15N power
supply module.
FUSE
10A
