Huntleigh SC300 - Rear Panel Controls Identification; Side Panel Controls Identification

11
3.2 Identifi cation of rear panel controls
1 Loudspeaker
2 Equipotential post
3 RS232 Service port
4 AC Power connector
5 Product identifi cation label
4
2
1
3
5
3.3 Identifi cation of Side panel controls
1 NiBP connector
2 SpO2 connector
1
Wireless Infra red thermometer
IRT10 (option)
2 Thermometer lens (option)
Left Right
2
1
2
1
Description of Controls, Indicators, Symbols and Displays
