Open the juice cap and insert the juice
cap seal in.
Organize the seal to seal off com-
pletely.
Insert it in from the top to the juice cap.
Be careful not to drop the chamber.
If the seal is not completely sealed, it may cause
juice leaking.
Hold juice cap seal as shown to the left.
As shown to the left in a dotted circle, the hole must
be visible when you hold.
www.hurom.com l 21
JUICE CAP SEAL ASSEMbLY
Juice cap seal
3
2
1
