Husqvarna 105 User Manual

64 - English
8. MAINTENANCE
8.7 Blades
There are three blades on the robotic lawnmower,
which are screwed into the blade disc. All three blades
and screws must be replaced at the same time to
obtain a balanced mowing system.
Use Husqvarna genuine blades only.
To replace the blades:
1. Set the main switch in position 0.
2. Wear protective gloves.
3. Turn the robotic lawnmower upside down.
4. Rotate the skid plate so that its holes align with
the screw for the blade.
5. Remove the 3 screws. Use a straight slot or
cross-tip screwdriver.
6. Remove the blade and the screw.
7. Screw on the new blade and the new screw.
8. Check also that the blade can pivot freely.
WARNING
Always use original blades and screws
when replacing. Only replacing the
blades and reusing the screw can result
in a screw wearing during mowing and
shearing. The blades can then be
propelled from under the body and
cause serious injury.
3012-1023
3012-272
3018-087

Husqvarna 105 Specifications

General

Model	105
Cutting Height Min	20 mm
Cutting Height Max	50 mm
Battery Type	Li-ion
Typical Charging Time	50 min
Typical Mowing Time per Charge	70 min
Maximum Incline Inside Working Area	25 %
Type	Robotic Lawn Mower
Working area capacity	600 m²
Maximum incline within the working area	25%
Cutting system	3 pivoting razor blades
Sound level Measured	58 dB(A)
Battery capacity	2.1 Ah
Cutting Width	17 cm
Weight	6.7 kg
