What causes a Husqvarna 555 XP carburettor to leak fuel?
If the carburettor on your Husqvarna Chainsaw is leaking fuel, it could be due to a loose or faulty fuel pipe, a hole in the diaphragm, a worn needle/needle tip, or a sticking control system. Other potential causes include a control system set too high, a leaking control system, or a loose cover on the carburettor pump side.
Why is the idling uneven on my Husqvarna Chainsaw?
Uneven idling in your Husqvarna Chainsaw can be caused by several factors: a blocked fuel filter or fuel line, a leaking inlet hose, or loose carburettor mounting. Other potential issues include a worn throttle valve axle, a loose throttle valve screw, a worn throttle valve, a leaking control system, or a worn control system’s centre knob. A hole or leaking diaphragm/cover plate, or a leaking crankcase could also be the cause.
Why does my Husqvarna Chainsaw engine stop when I release the throttle?
If your Husqvarna Chainsaw engine stops when you release the throttle, it could be due to a faulty pump diaphragm, a control system set too high or sticking, or a faulty diffuser jet.
What causes too rich idling in a Husqvarna 555 XP Chainsaw?
Too rich idling in your Husqvarna Chainsaw can be caused by a worn needle/needle tip, a worn lever arm in the control system or a leaking diaphragm/cover plate.
Why is there too much fuel at idle speed in my Husqvarna 555 XP Chainsaw?
If there's too much fuel at idle speed in your Husqvarna Chainsaw, it could be due to a worn needle/needle tip or a leaking diaphragm/cover plate.
Why won't my Husqvarna 555 XP run at full throttle?
If your Husqvarna Chainsaw won't run at full throttle, consider these potential issues: a blocked air filter, clogged tank venting, a blocked fuel filter or fuel line, or a loose or faulty fuel pipe. Other possible causes include a leaking or blocked impulse channel, a loose cover on the carburettor pump side, a faulty pump diaphragm, a leaking inlet hose, or loose carburettor mounting. The control system could be set too low, damaged, incorrectly assembled, sticking, or there might be a leaking diaphragm/cover plate. Finally, a blocked muffler could also be the reason.
Why does my Husqvarna 555 XP have low power?
If your Husqvarna Chainsaw is showing low power, the issue might stem from several components. Check for a clogged tank vent, a blocked fuel filter, a leaking or blocked impulse channel, or a loose cover on the carburettor pump side. A faulty pump diaphragm, a blocked air filter, a sticking or incorrectly assembled control system, or a leaking control system could also be responsible. Other potential causes are a loose or hole in the diaphragm, or a leaking diaphragm/cover plate.
Why my Husqvarna 555 XP will not 'four stroke'?
If your Husqvarna Chainsaw will not “four stroke”, the issue might be due to a clogged tank vent, blocked fuel filter or fuel line, or a loose or faulty fuel pipe. Other possible causes include a leaking or blocked impulse channel, a loose cover on the carburettor pump side, a faulty pump diaphragm, a leaking inlet hose, or loose carburettor mounting. The control system could be set too low, leaking, incorrectly assembled, or there may be a loose or holed diaphragm, or a leaking diaphragm/cover plate.
Essential safety information, general and special instructions for safe operation and repair.
Explains symbols found on the chainsaw and within the workshop manual.
Key engine, ignition, fuel, chain, drive, operating, and weight specifications.
Lists and illustrates essential tools required for servicing the chainsaw.
Provides critical torque values and lubrication points for assembly and repair.
Procedures for dismantling and assembling the chain brake and muffler systems.
Instructions for servicing chain catcher, start/stop control, and throttle control.
Detailed procedures for servicing starter, ignition, flywheel, and centrifugal clutch.
Instructions for servicing intake system, carburetor, fuel filter, and pump.
Carburettor design, function, dismantling, assembly, and testing procedures.
Lists common operating faults and their probable causes for starting, idling, and performance.
Outlines specific procedures for diagnosing and resolving issues.
General| Engine displacement | 59.8 cm³ |
|---|---|
| Power output | 3.5 kW |
| Recommended bar length | 13-20 inches |
| Chain pitch | 3/8 inch |
| Chain gauge | 0.058 inches |
