TECHNICAL DATA
Technical data
Speed and wire speed
Recommended diamond wire
Power - max, kW/hp
WS 440 HF 13/17.5
WS 482 HF 19/25.6
Speed, rpm 0-1200
Starting torque, Nm
WS 440 HF 100
WS 482 HF (Gear 2) 160
Magazine capacity, m/ft 10/33
Wire capacity, m/ft 1,9-11,7 / 6-38
Weight, kg/lbs
WS 440 HF 135/298
WS 482 HF 138 / 304
Direction of rotation Both directions
Degree of protection IP 65
Wire speed (at 1200 rpm), m/s / ft/s 24/79
Noise emissions (see note 1)
Sound power level, measured dB(A) 99
Sound power level, guaranteed L
WA
dB(A) 100
Sound levels (see note 2)
Sound pressure level at the operators ear, dB(A) 86
Spindle speed, rpm Wire speed, m/s Wire speed, ft/s
1000 20 66
1100 22 72
1200 24 79
Model
Abrasive
materials
Lime concrete Reinforcement degree
Low Medium High
C 710 - - Good Optimal Good
C 760 Acceptable Good Optimal Good Acceptable
C 1000 Good Good Good Optimal Good
C 1200 Good Acceptable Acceptable Good Optimal
