En
lish – 9
ASSEMBLING AND ADJUSTMENTS
• Mount the saw motor in the saw carriage.
• Mount the guard bracket on the saw motor. Screw the
fixing knobs down to lock the guard bracket.
• Mount the drive wheel on the saw motor. Fasten the
locking screw to lock the drive wheel.
• Mount the upper magazine on the rail. Align the pin on the
magazine mounting with the hole on the rail.
!
WARNING! The cutting arm should always
point in the same direction as the rail. The
depth feeding function must not be used
when sawing with a wire. Carelessness can
result in serious personal injury or even
death.
NOTICE! Ensure that the plastic cover on the saw is pointed
upwards when the saw is wall mounted, in order to prevent
water and dirt from accumulating inside the cover.
