8. Remove the rear discharge deflector in the
opposite sequence.
To install the grass catcher
(accessory)
The product can be used with a grass catcher.
1. Put the cutting deck in the transport position.
Refer to
To set the cutting deck in transport
position or mow position on page 17
.
2. Remove the rear discharge deflector (accessory)
or the mulch plug (accessory) if it is installed.
3. Put the discharge chute through the back plate
and into the chute adaptor for the cutting deck.
4. Install the 2 wing nuts.
5. Install the grass catcher.
6. Remove the grass catcher in the opposite
sequence.
Maintenance
Introduction
WARNING: Read and understand
the safety chapter before you do
maintenance on the product.
2010 - 003 - 10.04.2023 21
