20 TECHNICAL DATA
124
Spring rate
Weight of rider: 15 … 25 kg (33 … 55 lb.) 1.8 N/mm (10.3 lb/in)
Weight of rider (standard): 25 … 35 kg (55 …
77 lb.)
2.0 N/mm (11.4 lb/in)
Weight of rider: 35 … 45 kg (77 … 99 lb.) 2.2 N/mm (12.6 lb/in)
Spring length with preload spacer(s) 337.5 mm (13.287 in)
Fork oil per fork leg 240±10 ml (8.11±0.34 fl. oz.) Fork oil (SAE 4) (48601166S1)
( p. 127)
20.8 Shock absorber
20.8.1 TC 50
Shock absorber article number 03.18.7Q.02
Shock absorber WP Performance Systems 3614 DCC
Compression damping, low-speed
Comfort 18 clicks
Standard 15 clicks
Sport 12 clicks
Compression damping, high-speed
Comfort 2.5 turns
Standard 2 turns
Sport 1.5 turns
Rebound damping
Comfort 17 clicks
Standard 15 clicks
Sport 13 clicks
Spring preload
Standard 3 mm (0.12 in)
Spring rate
Weight of rider: 15 … 25 kg (33 … 55 lb.) 30 N/mm (171 lb/in)
Weight of rider (standard): 25 … 35 kg (55 …
77 lb.)
35 N/mm (200 lb/in)
Weight of rider: 35 … 45 kg (77 … 99 lb.) 40 N/mm (228 lb/in)
Spring length 130 mm (5.12 in)
Gas pressure 10 bar (145 psi)
Static sag 12 mm (0.47 in)
Riding sag 80 mm (3.15 in)
Fitted length 275 mm (10.83 in)
Shock absorber oil Shock absorber fluid (SAE 2.5)
(50180751S1) ( p. 128)
20.8.2 TC 50 Mini
Shock absorber article number 03.18.9Q.01
Shock absorber WP Performance Systems 3614 BAEM
