Note: to scroll down the parameters without changing
them, press the DOWN button.
List of Parameters
Here is a list of the parameters that can be changed in
the Second Level of programming, as well as their
options and ranges.
Parameter/Display Symbol Description Range / Options
Display Status dSPL Information shown on
the display during operation
conditions
tdAy – time-of-day
rSP° – zone temperature
(refrigerated space)
CyCL – cycle between time
and zonetemperature
Epr° – evaporator coi
temperature
Clock Format CLHr Format of the time (12
or 24 hours mode)
12Hr – AM/PM format
24Hr – 24 hour format
TemperatureFormat °dSPTemperature degrees °F –
degrees Fahrenheit°C – degrees
Celsius
Defrost Type dFtP Type of defrost used in
the application
ELEC – electric heater defrost / off
cycle
HgAS – hot gas–
Fan Status During Defrost
EFAN Enable or not the fan
during defrost
no – fan is turned off during
defrost
yES – fan remains on during
defrost
Defrost Interval dFin Type of defrost interval
TdAy – time-of-day setpoint
CPrn – compressor run time
tdEF–– temperature initiated
defrost
Minimum Compressor Off Time
CoFF Minimum time that the
compressor will remain turned off
Range: from 0 to 15 min
Minimum Compressor On Time
Con Minimum time that the
compressor will remain turned on
Range: from 0 to 15 min
Alarm Delay ALrd Time delay before the
alarm goes off after the
temperature fall off the two alarm
setpoints Range: from 0 to 59 min
Compressor Run Time
CPrn Time the compressor
will run between defrosts
Number of Defrosts nodF Number of defrosts per
day from 0 to 8 (0 means 1 defrost
every 48 hours)
Defrost Start Time dEF1-8 Start time of each
defrost
Defrost Duration dEFd Defrost duration time
(back-up for defrost termination
temperature) Range: from 0 min
to 4 hours
Fan Delay FAnd Delay time for the fan after defrost
(back-up for fan cut-in
temperature) Range: from 0 to 15
min
Pump Down Pudn Pump down duration
Range: from 0 to 59 min
Drip Time driP Drip time duration Range: from 0 to
59 min
Setpoint Differential diF° Cut-in temperature
differential Note: cut-in is cut-out
plus differentialRange: from 1 to 25°
Temperature Initiated Defrost tdEF Temperature
that will initiate a defrost cycle
Range: from – 40 to 40°F or–– 40 to
4°C
Defrost Termination Temperature dEF°
Temperature in the evaporator that
will terminate the defrost cycle
Range: from 0 to 75°F or –18 to
25°C
Fan Cut-In Temperature FAn° Temperature in the
evaporator that will turn the fan on
after defrost Range: from – 40 to
60°F or–– 40 to 23°C
Paragon ERC 2 Electronic Controller for Self Contained Cases Cont’d
