IGSF-ASC-L / ASCS-L-0308
14
Electrical
WIRING COLOR CODE
GREEN GROUND
PURPLE ANTI-SWEAT
ORANGE LIGHTS
YELLOW RECEPTACLE
RED / BLACK T-STAT /SOLENOID230V
BLACK / WHITE T-STAT / SOLENOID 115V
BROWN FAN MOTORS
CASE MUST BE GROUNDED
NOTE: Refer to label affixed to case to determine the actual
configuration as checked in the “TYPE INSTALLED” boxes.
ELECTRICAL CIRCUIT IDENTIFICATION
Standard lighting for all models will be full length
fluorescent lamps located within the case at the top.
The switch controlling the lights, the plug provided for
digital scale, and the thermometer are located at the
rear of the case mullion.
ELECTRICAL SERVICE RECEPTACLES
(WHEN APPLICABLE)
The receptacles located on the exterior of the
merchandiser are intended for scales and lighted
displays. They are not intended nor suitable for large
motors or other external appliances
.
BEFORE
SERVICING
Always Disconnect Electrical
Power at the Main Disconnect
when servicing or replacing
any electrical component.
This includes (but not limited to) Fans,
Heaters, Thermostats, and Lights.
FIELD WIRING & SERIAL PLATE AMPERAGE
Field Wiring must be sized for component amperes
printed on the serial plate. Actual ampere draw may be
less than specified. Field wiring from the refrigeration
control panel to the merchandisers is required for re-
frigeration thermostats. Most component amperes are
listed in the “Case Specs” section, but always check the
serial plate.
BALLAST LOCATION
Ballasts are located on the right rear panel. Refer to dia-
gram on page 6.
WIRING & SERIAL PLATE AMPERAGE
Field Wiring must be sized for component amperes
stamped on the serial plate. Actual ampere draw may
be less than specified. Field wiring from the refrigeration
control panel to the merchandisers is required for
refrigeration thermostats. Most component amperes
are listed in the "Case Specs" section, but always check
the serial plate.
ASHRAE COLOR CODE
NOTE: All other manufacturers; no known sensor codes
Case Control Systems SENSOR COLORS
Manufacturer ® > EIL CPC
Location
Coil Inlet
Color
Blue Blue
Part#
225-01-1755225-01-325
Coil Outlet
Color
Red Red
Part#
225-01-1757225-01-312
Discharge Air
Color
Green Green
Part#
225-01-1756225-01-326
Return Air
Color
Purple Green
Part#
225-01-1758225-01-326
Defrost Term.
Color
White Orange
Part#
225-01-0650225-01-325
Liquid Line
Color
White Blue
Part#
225-01-0650225-01-325
