Rev. 0308
13
Zone Temperature Sensor:
NTC thermistor. Range – 40 to
199°F
Evaporator Coil Sensor:
NTC thermistor. Range – 40 to
199°F
Ambient Operating Conditions:
– 40 to 122°F; 0 to 95% RH (non-
condensing)
Display Module Dimensions:
2.75”W x 1.10”H x 1.38”D
Case Dimensions:
4.40”W x 7.28”H x 3.80”D
Shipping Weight: 2.7 lbs.
Agency Approvals:c-UR-us Recognized Component
(equivalent to UL and CSA
certifications)
NSF International Certified
OUTPUT RELAY RATINGS:
COMPRESSOR: SPST NO
120 VAC 208 VAC 240 VAC
Horsepower Rating (hp) 1 1.5 2
FLA / LRA 16 / 96 12 / 72 12 / 72
Pilot Duty 470 470 470
DEFROST: SPST NC
120 VAC 208 VAC 240 VAC
Resistive Amps 16 16 16
Horsepower Rating (hp) 1/2 3/4 1
Pilot Duty (VA) 470 470 470
EVAPORATOR FAN: SPST NC
120 VAC 208 VAC 240 VAC
Resistive Amps 16 16 16
Horsepower Rating (hp) 1/2 3/4 1
FLA / LRA 10 / 59 8 / 48 8 / 48
Pilot Duty (VA) 470 470 470
ALARM: SPST NO
120 VAC 208 VAC 240 VAC
Resistive Amps 5 5 5
Pilot Duty (VA) 240 240 240
Ä
PARAGON
Commercial Refrigeration Controls
Ranco North America
8115 US Route 42N
Plain City, OH 43064
Te lephone: 614 873 9000
Facsimile: 614 873 9332
An Invensys Company
Part # 7515008-001 September 99
Paragon ERC 2 Electronic Controller for Self Contained Cases Cont’d
