Hussmann ASC-L - Electrical and Refrigeration Specifications; ASC-L; ASCS-L (Gelato) - Electric Defrost; ASC-L; ASCS-L (Ice Cream) - Electric Defrost

IGSF-ASC-L / ASCS-L-0308
18
Electrical and Refrigeration Specifications
Model Refrigeration Average Disch. Air T~Stat Coil Fan Blade Qty. Defrosts Elec. Load (Amps) @ ~115 VAC
& Btu / Hr. Temperatures (°F) Speed Settings Type Size(in) & Evap. per day Fans Case Case Std.
Length (Ft.) (Total) Evap. Prod. Disch. (FPM) (°F) Pitch ( ° ) Fans Min. Qty. Std. Warmer Lights Defrost Outlet Drain
ASC-L / ASCS-L (Gelato) - Electric Defrost Option
4' Frozen food 650 2,600 -5° 10° 5° 120 5° Forced 4
1
/2”130 2 0.18 0.35 1.83 15.65 15.0 1.04
Air Axial (115V) (115V)
6' 650 3,900 -5° 10° 5° 120 5° Forced 4
1
/2”2 30 2 0.36 0.52 1.83 23.48 15.0 1.57
Air Axial (115V) (115V)
8' 650 5,200 -5° 10° 5° 120 5° Forced 4
1
/2”2 30 2 0.36 0.70 1.83 17.31 15.0 1.15
Air Axial (208V) (208V)
10' 650 6,500 -5° 10° 5° 120 5° Forced 4
1
/2”3 30 2 0.54 0.87 3.05 21.63 15.0 1.44
Air Axial (208V) (208V)
12' 650 7,800 -5° 10° 5° 120 5° Forced 4
1
/2”4 30 2 0.72 1.04 3.05 25.96 15.0 1.73
Air Axial (208V) (208V)
ASC-L / ASCS-L (Gelato) - KOOL-GAS™ Defrost Option
4' 650 2,600 -5° 10° 5° 120 5° Forced 4
1
/2”1 16 1 0.18 0.35 1.83 15.0 1.04
Air Axial (115V)
6' 650 3,900 -5° 10° 5° 120 5° Forced 4
1
/2”2 16 1 0.36 0.52 1.83 15.0 1.57
Air Axial (115V)
8' 650 5,200 -5° 10° 5° 120 5° Forced 4
1
/2”2 16 1 0.36 0.70 1.83 15.0 2.09
Air Axial (208V)
10' 650 6,500 -5° 10° 5° 120 5° Forced 4
1
/2”3 16 1 0.54 0.87 3.05 15.0 3.48
Air Axial (208V)
12' 650 7,800 -5° 10° 5° 120 5° Forced 4
1
/2”4 16 1 0.72 1.04 3.05 15.0 3.13
Air Axial (208V)
ASC-L / ASCS-L (Ice Cream) - Electric Defrost Option
4' 450 1,800 -30° -10° -20° 150 -20° Forced 4
1
/2”1 30 2 0.18 0.35 1.83 15.65 15.0 1.04
Air Axial (115V) (115V)
6' 450 2,700 -30° -10° -20° 150 -20° Forced 4
1
/2”2 30 2 0.36 0.52 1.83 23.48 15.0 1.57
Air Axial (115V) (115V)
8' 450 3,600 -30° -10° -20° 150 -20° Forced 4
1
/2”2 30 2 0.36 0.70 1.83 17.31 15.0 1.15
Air Axial (208V) (208V)
10' 450 4,500 -30° -10° -20° 150 -20° Forced 4
1
/2”3 30 2 0.54 0.87 3.05 21.63 15.0 1.44
Air Axial (208V) (208V)
12' 450 5,400 -30° -10° -20° 150 -20° Forced 4
1
/2”4 30 2 0.72 1.04 3.05 25.96 15.0 1.73
Air Axial (208V) (208V)
ASC-L / ASCS-L (Ice Cream) - KOOL-GAS™ Defrost Option
4' 450 1,800 -30° -10° -20° 150 -20° Forced 4
1
/2”1 16 1 0.18 0.35 1.83 15.0 1.04
Air Axial (115V)
6' 450 2,700 -30° -10° -20° 150 -20° Forced 4
1
/2”2 16 1 0.36 0.52 1.83 15.0 1.57
Air Axial (115V)
8' 450 3,600 -30° -10° -20° 150 -20° Forced 4
1
/2”2 16 1 0.36 0.70 1.83 15.0 2.09
Air Axial (208V)
10' 450 4,500 -30° -10° -20° 150 -20° Forced 4
1
/2”3 16 1 0.54 0.87 3.05 15.0 3.48
Air Axial (208V)
12' 450 5,400 -30° -10° -20° 150 -20° Forced 4
1
/2”4 16 1 0.72 1.04 3.05 15.0 3.13
Air Axial (208V)
Set (PSI) Size Voltage Ampacity
Out In (HP) (VAC)
ASC-L / ASCS-L (GELATO) -Electric Defrost Option
4' 30 50 1/2 115 11.1
6' 30 50 3/4 115 15.6
8' 30 50 3/4 208/230 8.5
10' 30 50 1 208/230 10.6
12' 30 50 1 1/4 208/230 11.0
ASC-L / ASCS-L (GELATO) -KOOL-GAS™ Defrost Option
4' 30 50 1/2 115 11.1
6' 30 50 3/4 115 15.6
8' 30 50 3/4 208/230 8.5
10' 30 50 1 208/230 10.6
12' 30 50 1 1/4 208/230 11.0
