Hussmann FWEG - Electric Defrost - Standard

6 of 7 FWEG Technical Data Sheet
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
Red
208 V Power From Defrost Contactors
L1
L2
Electric Defrost Heaters
Drip Pan Heater
6
Red
5
Defrost Termination Thermostat
Dark Blue
To
Condensing Unit
}
3
Light Blue
2
To
Condensing Unit
}
Refrigeration Thermostat (Optional)
1
BROWN BAND
Fan
BROWN BAND
Nosing
Anti-sweat
Heater
120V POWER
120V NEUTRAL
89
Return Grille
Anti-sweat
Heater
WARNING
All components must have mechanical ground, and the merchandiser must be grounded.
Circled Numbers = Parts List Item Numbers.
10
White
Purple
Return Glass Anti-sweat Heater
120V
POWER
120V
NEUTRAL
10
White
Purple
10
Electric Defrost – Standard
