Hussmann IMPACT D5L - Refrigeration Data; Defrost Data; Physical Data

REFRIGERATION DATA
Note: This data is based on store temperature
and humidity that does not exceed 75°F and
55% R.H.
D5L D5LE
Discharge Air °F 31 32
Evaporator °F 21 24
Unit Sizing °F 19 22
Btu/hr/ft* D5L D5LE
L
IT &U
NLIT SHELVES
Parallel 1495 1425
Conventional 1580 1515
H
USSMANN PEG SHELVES (DELI ONLY)
Parallel 1615 1545
Conventional 1700 1635
*For all refrigeration equipment other than
Hussmann, use conventional Btu values.
DEFROST DATA
Frequency Hrs 66
Defrost Water (lb/ft/day) 10.25
(± 15% based on case configuration and
product loading).
OFFTIME D5L D5LE
Temp Term °F 48 48
Failsafe Minutes 30 35
E
LECTRIC OR GAS
Not Recommended
Standard Defrost Thermostat
Close on rise: close 48°F — open 33°F
CONVENTIONAL CONTROLS
Low Pressure Backup Control
CI/CO** D5L D5LE
14°F / 4°F 17°F / 7°F
Indoor Unit Only, Pressure Defrost
Termination** 48°F
**Use a Temperature Pressure Chart to
determine PSIG conversions.
PHYSICAL DATA
Merchandiser Drip Pipe (in.) 1
1
/2
Merchandiser Liquid Line (in.)
3
/8
Merchandiser Suction Line (in.)
7
/
8
Estimated Charge (lb)***
D5L D5LE
8 ft 2.3 2.7
12 ft 3.3 3.9
***This is an average for all refrigerant types.
Actual refrigerant charge may vary by
approximately half a pound.
Length Added to Lineup by End or
Insulated Partition (in.) 1
1
/2
3 of 6
P/N 0378426E
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
Impact D5L
Dairy & Delicatessen
Dimensions shown as in. and (mm).
Multi-deck, 5 Display Levels
NSF Certification
These merchandisers are manufactured to meet ANSI /National
Sanitation Foundation (NSF
®
) Standard #7 requirements.
4
(102)
C
O
I
L
61
(1549)
81
3
/8
(2066)
45
5
/8
(1159)
D5L
FAN
5
3
/4
(146)
19
(483)
3
1
/8 (79)
56
1
/4
(1429)
7
1
/2
(152)
7
(178)
46
1
/4 (1174)
27
1
/2 (699)
30
1
/8
(765)
4
1
/4
(108)
29
1
/2 (749)
4
1
/2
(114)
38
5
/8 (981)
2
3
/4 (70)
53
5
/8
(1360)
14
1
/8
(359)
6
1
/8
(155)
