Hussmann microSC MDN4775B1A - Direct Drain

P/N 9FQ6P11007900_B 4-3
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
Open Vertical Merchandisers
Condensing Unit
Cassette
● （Below is an example of MDN-4775A.）
②
Front panel
Evaporation tray
③
③
⑤
④
Unit
② Remove 2 screws of the front panel, then the panel itself.
① Disconnect the power cord.
③ Remove 8 screws in the area shown by in the gure.
④ Pull out the unit.
⑤
Unplug
⑤ Remove 3 screws attached to the evaporation tray
(Marked with in the gure at right.)
Step 1
DIRECT DRAIN
The evaporation system can be modied for a
direct oor drain.
Display Case
Disconnect the power cord.
Remove 2 screws of the front panel, then the panel itself.
Remove 8 screws in the area shown by
in the gure.
Step 1
Unplug
Pull out the unit.
Front panel
Remove 3 screws attached to the evaporation tray
(Marked with in the gure at right.)
