3-6 startup / operatIon
P/N 3113125_A U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • www.hussmann.com
TYPICAL SENSOR LOCATION
Green
Detail A
EVAPORATOR
(ISOMETRIC REAR VIEW)
B
DETAIL B
Protective
Tube
Defrost Sensor located in
middle of Evaporator Coil.
NOTE:
It is critical for merchandiser operating
performance to have the sensors in this
location. If for any reason, the sensors are
removed, they need to be placed in the
original location.
To Next Page
