HUSTLER Super 104 - Operation; Safe Operating Practices; Control Panel

REV B 4-4 125816
Steering control lever shown in park brake position
A. Steering control levers
Figure 4-6
A. Steering damper spring housing
B. Rear ball stud
Figure 4-7
A
A
A
B
A. Cap screws
Figure 4-8
A. Align steering control lever ± .125” (3.175 mm)
Figure 4-9
A
A
