HUSTLER Super 104 - General Engine Maintenance; Belts

REV B 6-2 125816
Drive wheels . . . . . . . . .15–20 psi (103–138 KPa)
Front wheels. . . . . . . . .20–25 psi (138–172 KPa)
2. Park the unit on a flat surface.
3. Raise the center deck and latch in the transport
position.
4. Place the height stop pin in the 3.25” (82.6 mm) hole.
A. Measure to top of deck here
B. 3" block
Figure 6-3
A
A
A
A
B
B
B
B
B
B
A. 3" block B. Locator triangles
Figure 6-4
Side view
B
A A
A. Square hole
B. 1/2" break-over bar
C. 1/2" extension
Figure 6-5
A
B
C
