NEW SMPS Installation for reference
□ In case of using a main light, Halogen (HS-5000, HS-5500, HS-7000, HS-7500)
4 3 2 1
ON
1. Connect main light connector to CON4(HALOGEN)
2. Adjust the switch as above the picture.
* Only for HS-5000, HS-5500, HS-7000, HS-7500
1
2
To Next Page
