Customer Service Department
HUVITZ Co.,Ltd
2013. 08. 16
58 / 72
NEW SMPS Installation for reference
4 3 2 1
ON
1. Connect main light connector to CON10 (MAIN_LED)
2. Adjust the switch as above the picture.
* Only for HS-5000, HS-7000
1
2
□ In case of using a main light, LED LAMP(5000/7000) + LED auxiliary light(5000/7000)
To Next Page
