Installation and Maintenance Manual
57
GATE
OPERATOR
26"W X 26"H
X 14
1
2
"D
GATE OPENING
8" X 8
1
2
" ELECTRICAL
ACCESS (2
1
2
" FROM CORNER)
DRIVE RAIL
GATE PANEL
30"W X 42"H
X 12"D
CONCRETE SLAB
POWER
SUPPLY
WHEEL
COVERS
DC POWER SUPPLY
30"W X 30"H
X 12"D
RIGHT HAND GATE SHOWN. REVERSE ENCLOSURE
FOR LEFT HAND INSTALLATION.
DRIVE UNIT
PUMP AND
ELECTRICAL
ENCLOSURE
OR
1
OFFSET 3"
3
4
"
DC REMOTE POWER PACKAGE
FRONT VIEW END VIEW
PLAN VIEW
seattle, washington
TITLE
DRAWING NUMBER
1 1
SHT OF
THIRD ANGLE PROJECTION
SS20
REVDRAWN
APPROVED
CHECKED
DATE
DATE
DATE
7/27/0KERI
ERN NUMBER
-
--
--
ERN000010 5/16/00
DATE
HEATER IS SUPPLIED.
ADD 2 14 GA.MINIMUM IF DRIVE UNIT
2 GA. MINIMUM FOR 2 HP MODELS
6 GA. MINIMUM FOR 1 HP MODELS
2 EA. HEAVY GAUGE FOR MOTOR.
4 EA. 14GA.MINIMUM FOR CONTROL PANEL
4 CONDUCTORS REQUIRED
POWER SUPPLY WIRING TO DRIVE UNIT:
4 BATTERY, 170AH: AS SHOWN.
2 BATTERY, 90AH: 30"W X 30"H X 12" D
D.C. POWER BATTERY PACKS
GREATER THAN 10 FEET.
OPERATOR. CONTACT FACTORY IF DISTANCE IS
SHOULD BE LOCATED WITHIN 10 FEET OF
WHEN POSSIBLE, ELECTRICAL ENCLOSURE
ALIGNMENT OF ALL COMPONENTS.
ELECTRICAL ENCLOSURE WILL HELP ASSURE
ONE SLAB TO SUPPORT OPERATOR AND
ARE 4" MINIMUM. POSTS AND HARDWARE ARE
FOR PASSAGE OF ELECTRICAL WIRES.
CONNECTED BY A MINIMUM 2" ROUND CONDUIT
DRIVE UNIT AND POWER PACKAGE MUST BE
CHECK LOCAL CONDITIONS.
16" DEEP OR TO THE FROST LINE.
CONCRETE FOOTINGS MUST BE A MINIMUM OF
SUPPORT POSTS FOR ELECTRICAL ENCLOSURE
BY OTHERS.
NOTES:
DRIVE UNIT
FENCE LINE
GATE PANEL
