Operating mode - MANU - OPERATOR (MANU2)
MENU1 -> MANUAL -> Operator -> Continue
F1
F2
F3
F4
= back to "Manual1" Menu
VP = Switching vacuum pump on/off
RV = Switching return valve on/off
WDV = Switching off the water drainage valve
(present only with water ring vacuum pump)
Operating mode - MANU - OPERATOR (MANU3)
MENU1 -> MANUAL -> Operator -> Continue -> Continue
F1
F2
F3
F4
= back to "Manual2" Menu
H = Switching heater on/off (only with option heater)
CSP = Switching conveyor pump for ContaminationSensor On/Off
(option: ContaminationSensor)
WFV = Switch water filling valve On/Off
(Optional: only with water ring vacuum pumps with automatic
water intake)
The operating menu for Service is password-protected. You are presently in the
registration screen, press "CANCEL".
"CANCEL" is accessed by simultaneously pressing the keys
TAB
+
+/-
. Afterwards,
press the
key and return to the manual mode selection.
OFF
NEXT
OFF
OFF
Manual 2
Exit
VP
RV
WDV
OFF
Cont.
OFF
OFF
Manual 3
Exit
H
CSP
WFV
