HydraMaster Boxxer 427 - Page 132

Page 7-2 Boxxer 427
HydraMaster Corporation
Figure 1-2 Solution Valve Assembly
B1234
ITEM PART NO. DESCRIPTION QTY
1 600-012-001 Valve Body Sub Assembly 1
2 600-012-002 Valve Stem Sub Assembly 1
3 155-003 Spring, HM Solution Valve 1
4 027-001 Cap, Brass 1
