Boxxer 427 Page 7-3
HydraMaster Corporation
Figure 1-3 Valve Stem Assembly
B3743
ITEM PART NO. DESCRIPTION QTY
1 107-129 Plunger, HM Solution Valve 1
2 139-003 Ring Keeper, HM Solution Valve 1
3 097-010 O-Ring, HM Valve Plunger - Large 1
4 097-022 O-Ring, Solution Valve Flow Meter - Small 1
5 139-004 Ring, Solution Valve Stem Snap 1
