HydraMaster Corporation
Boxxer 427 Page 1-67
Figure 1-32 Machine Right Side Cover Assembly
D-5762 Rev -
1 000-041-419 Cover, Right Side Machine - Boxxer 427 1
2 000-105-313 Plate, Hydramaster Name- Roto Tank 1
3 000-174-001 Washer, #10 Flat 2
4 000-143-166 Screw, #10-24UNC x 0.38" Lg. Hex Head 2
5 000-094-034 Nut, #10-24UNC Nylock 2
6 000-089-003 Magnet, Treadmaster 2
Machine Right Side Cover Assembly Parts List
Item Part Number Description Qty
5
6
6
5
1
2
3
4
3
4
