Page 1-84 Boxxer 427
Float Switch w/ Polypropylene Barrel Assembly Parts List
Item Part Number Description Qty
Figure 1-42 Float Switch w/ Polypropylene Barrel Assembly
C-6549 Rev -
1 - - - Stem, Float Switch 1
2 000-005-011 Float, Polypropylene Replacement- Boxxer 427 1
3 000-108-110 Shield, Poly Float Splash 1
4 000-139-010 Ring, Snap Ring (E-Clip) x 5/16" 2
1
4
2
4
3
