Outdoor Location
In selecting the ideal outdoor location for your spa, we suggest that you take into consideration:
1. The proximity to changing area and shelter (especially in colder weather conditions).
2. The pathway to and from the spa (free of debris, dirt, leaves as not to be tracked into
spa).
3. The closeness to trees and shrubbery (leaves and birds could create extra work).
4. A sheltered environment (less wind, weather exposure resulting in lowered operation
and maintenance costs).
Indoor Location
Be sure your spa will fit into the space you have chosen. Proper access into the home is needed to
move the spa into place. Ventilation may be needed because of the humidity from the spa. In most
cases, a spa cover is sufficient. Be sure to check the load carrying capabilities of the floor on which
you will be installing your spa. Most homes meet the requirement of 125lbs per square foot. Insure
you have proper drainage in the event of a leak. In case of maintenance problems; leave enough
room around the spa to work.
CHOOSING A LOCATION
POWER REQUIREMENTS
MODEL VOLTS GFCI AMPS EL RATING AMPS MARKING APPLICATION
Millennium 240 50 40 3 Wire #6 + Grd 3 HS200/HS200M7
Omni 240 50 40 3 Wire #6 + Grd 3 HS200/HS200M7
Solaris 240 50 40 3 Wire #6 + Grd 3 HS200/HS200M7
Stratus 240 50 40 3 Wire #6 + Grd 3 HS200/HS200M7
Lexxus 240 50 40 3 Wire #6 + Grd 3 HS200/HS200M7
Tiara 240 50 40 3 Wire #6 + Grd 3 HS200/HS200M7
Our spas are designed to provide optimum performance and flexibility of use when connected to
their maximum electrical service listed in the table below.
·US/Canada 60Hz Model: 240vac/40A (50A GFCI breaker)
If you prefer, our Service Department can assist you with a minor circuit board modification
("S1"switch "mode operation" ON/OFF in Controller) that allows the spa to operate on a different
electrical service.
Electrical Service Options for all Mark III models:
Voltage 240vac 240vac
Number and size of wires 3wires #6+GR 3wires #6 +GR
Frequency 60Hz 60Hz
Circuit breaker (2-Pole) 40A** 50A*
S1 position ON OFF
* In this configuration, the heater will operate while both jets pumps and blower are running
** In this configuration, the heater will not operate while either jets pump is running or when the
blower is running
For details See Wiring Diagram Fig. 1 Page 6, Fig. 1b Page 7, and GFCI Wiring Diagram Fig. 2
Page 8.
