DISPLAY MESSAGES - HS200 M7
Message Meaning Action required
No message on display. Power has been
cut off to spa.
The control panel will be disabled until power returns. The system
reset the time of day on each power up. Spa settings are pre-
served.
OHH "Overheat"- The spa has shut down. One
of the sensors detected 118egree F
(approximately 47.8 degree C) at the
heater.
Do not enter the water. Remove the spa cover and allow the
water to cool. Once the heater has cooled, reset by pushing any
button. If the spa does not reset, shut off the power to the spa and
call your dealer or service.
OHS "Overheat"- The spa has shut down. One
of the sensors detected that the spa
water is 110egree F (approximately 43.3
degree C).
Do not enter the water. Remove the spa cover and allow the
water to cool. At 107 degree F (approximately 41.7 degree F), the
spa should automatically reset. If the spa does not reset, shut off
the power to the spa and call your dealer or sevice.
ICE "Ice" - Potential freeze condition detected. No action required. The pumps and the blower will automatically
activate regardless of the spa status.
SnA Spa is shut down. The sensor that is
plugged into the "Sensor A" jack is not
working correctly.
Check the sensor "A" plug connection to circuit board. If the prob-
lem persists, contact your dealer or service. (The problem may
appear temporarily in an overheat situation and disappear when
the heater cools).
SnB Spa is shut down. The sensor that is
plugged into the "Sensor B" jack is not
working correctly.
Check the sensor "B" plug connection to circuit board. If the prob-
lem persists, contact your dealer or service. (The problem may
appear temporarily in an overheat situation and disappear when
the heater cools).
SnS Sensors are out of balance. If this is alter-
nating with temperature, it may just be
temporary condition. If the display shows
only this message (periodically blinking),
the spa is shut down.
If the problem persists, contact your dealer or service.
HFL A substantial difference between sensors
was detected. This could indicate a flow
problem.
Check water level in spa. Add water if necessary. Be sure that
slide-valves are open. Make sure the circulation pump have been
primed and has power.
LF Persistent low flow problems. Displays on
the fifth occurrence of the "HFL" message
within 24 hours. Heater is shut down, but
other spa functions to run normally.
Follow actions required for "HFL" message. Heating capacity of
the spa will not reset automatically; you may press any button to
reset or cycle the power off and on.
dr Inadequate water detected in heater.
Displays on third occurrence of "dr" mes-
sage. Spa is shut down for 15 minutes.
Check water level in spa. Add water if necessary. Be sure that
slide-valves are open. Make sure the circulation pump have been
primed and has power. On the third consective occurrence of the
dr message (without a successful heating cycle in between) the
panel will display dr4.
dr4 Inadequate water detected in heater.
Displays on third occurrence of "dr" mes-
sage. Spa is shut down and will not reset
in 15 minutes.
Check water level in spa. Add water if necessary. Be sure that
slide-valves are open. Make sure the circulation pump have been
primed and has power. Press any button to reset.
Pr When your spa is first activated, it will go
into Priming mode.
See the 24 hour circulation pump operation. The Priming mode
will last for up to four minutes and then the spa will begin to heat
and maintain the water temperature in Standard mode.
- F Temperature unknown After 6minutes Pr mode, the temperature will be displayed.
- C Temperature unknown After 6minutes Pr mode, the temperature will be displayed.
