Hydro EvoClean 1214GB - Replacement Parts

Page 25 Hydro Systems Co. 2018
11.1. Replacement Parts
Components shown on the following page should only be replaced by a competent engineer.
Any components not listed within this section should not be attempted to be replaced without the advice of Hydro Systems
Europe (Any unauthorised attempts to repair the unit will invalidate warranty).
CAUTION
Before any maintenance, isolate the incoming power source and disconnect.
ITEM # DESCRIPTION PART # NOTES
1
STRAINER WASHER 238100
INLET OPTION, 3/4“ FEMALE BSP
2
SWIVEL COLLAR 3/4“ BSP 10082835
3
SWIVEL STEM 10082801
4
WATER VALVE, 24vDC 10095315
5
VALVE NIPPLE 10075906
6
END PLUG 10075926
7
WALL BRACKET 10094361
8
EDUCTOR, 2LPM 10097802
EDUCTOR, 4LPM 10097801
9
HOSE BARB, 0.5 IN (12 MM) 90099387
HOSE BARB, 0.37 IN (10 MM) 90099388
10
EVOCLEAN CLIP, 10 PACK 10095123
11
SINGLE PORT MANIFOLD, 1-WAY TEE, PP 90099384
12
DOUBLE PORT MANIFOLD, 2-WAY TEE, PP 90099385
13
EVCL, CHK VLV, AF, 1/2 B X 1/4 FNPT, PT HS, PVC, MK2,
ASM (1)
90099463 NOT SHOWN
EVCL, CHK VLV, EP, 1/2 B X 1/4 FNPT, PT HS, PVC, MK2,
ASM (1)
90099464 NOT SHOWN
EVCL, CHK VLV, AF, 1/4NPT-F X 3/8IN BARB, MK2, ASM (1) 90099603 NOT SHOWN
EVCL, CHK VLV, AF, 1/4 FNPT X 1/4 FNPT, PT HS, PVC,
MK2, ASM (1)
90099604 NOT SHOWN
EVCL, CHK VLV,AF, 5/16 B X 1/4 FNPT, PT HS, PVC, MK2,
ASM (1)
90099605 NOT SHOWN
EVCL, CHK VLV, EP, 3/8 B X 1/4 FNPT, PT HS, PVC, MK2,
ASM (1)
90099606 NOT SHOWN
EVCL, CHK VLV, EP, 5/16 B X 1/4 FNPT, PT HS, PP, MK2,
ASM (1)
90099607 NOT SHOWN
EVCL, CHK VLV, EP, 5/16 B X 1/4 FNPT, PT HS, PVC, MK2,
ASM (1)
90099608 NOT SHOWN
14
MANIFOLD END PLUG 90099390 NOT SHOWN, PLUG
15
PIPE NIPPLE 10075904
16
15MM PUSHFIT BODY 90094370
INLET OPTION, 15MM PUSHFIT
17
PUSHFIT O-RING 10096188
18
PUSHFIT STRAINER 10094764
19
EPDM WASHER, 10 PACK 10095173 NOT SHOWN, USED IN ITEMS 8
20
EPDM O-RING, 10 PACK 10098127 NOT SHOWN, USED ON ITEMS
4,5
21
AFLAS O-RING, 10 PACK 10098128 NOT SHOWN, USED ON ITEMS
10,11,13,14, 15
22
LOCK KEY 10097834 NOT SHOWN
23
MAIN UNIT FRONT LABEL PACK 10098135
24
USB COVER 10097831
