Page 23
6.2 Water discharge
Risk of scalding!
During blow down up to 0.3 l/sec (.08 gal./
sec) are being drained with a temperature of
about 95 °C (203 °F).
Ensure that the drain hose is reliably fas-
tened and wastewater can drain freely and
pressureless.
Humidifier kit installation location and waste-
water discharge must be on the same pres-
sure level.
Guidelines for water discharge composi-
tion
• Do not buckle drain hose
• Discharge line and drain pipe material
must be temperature resistant up to
95 °C (203 °F)
How to proceed
» Fit 14 mm (.55 inch) drain hose with
a clamp to the wastewater connec-
tion and run into a pressure-free out-
let according to DIN EN 1717.
6.3 Water connections final
check
Go down the following water installation
checklist:
All screws and clamps properly tigh-
tened?
Water supply line flushed before
making connections?
Water connection properly installed?
Water discharge properly installed?
Does blow-down water drain freely?
Water supply line and water
discharge leakage-free?
