13. Technical specifications
Unit type KIT E02 KIT E10
Steam output [kg/h] 1,9 - 2,1 4,4 - 4,8 5,6 - 6,3 9,5 - 10,4
Electrical connection
(1)
Rated power [kW] 1,4 - 1,6 3,3 - 3,6 4,2 - 4,7 7,1 - 7,8
Nominal current [A] 6,5 15 6,5 10,8
Fuse [A]
(2)
1 x 10 1 x 20 3 x 10 3 x 16
Control
Control voltage separate
Steam hose connection [mm]
Water consumption
(7)
[l/h]
2,5 5,8 7,5 12,5
Water flow rate
(8)
[l/min]
Max. filling capacity [l] 2,9 4,8
Empty weight [kg] 3,4 4
Operation weight [kg] 8 9
Width [mm]
Height [mm] 400 550
Depth [mm]
Water connection
Drain water connection
optional: Standard
Technical data SteamKit E (Electrodes)
KIT E06
220 - 240V /1Ph /N /50-60Hz 380 - 415V /3Ph /N /50-60Hz
2,6
3,6
220 - 240V / 1,6A
1 x 25
1,3
tap water of varying qualities
1 to 10 bar, 3/4" external thread
Connection Ø 1 1/4"
530
220
7
300
Unit type KIT E15 KIT E20 KIT E30 KIT E45 KIT E65
Steam output [kg/h] 14,2 - 15,5 19,0 - 20,8 28,5 - 31,1 42,7 - 46,7 61,8 - 67,5
Electrical connection
(1)
Rated power [kW] 10,7 - 11,6 14,3 - 15,6 21,4 - 23,4 32,1 - 35 46,3 - 50,6
Nominal current [A] 16,2 21,7 32,5 48,7 70,4
Fuse [A]
(2)
3 x 20 3 x 32 3 x 40 3 x 63 3 x 80
Control
Control voltage separate
Steam hose connection [mm]
Water consumption
(7)
[l/h]
18,6 25,0 37,3 56,0 81,0
Water flow rate
(8)
[l/min]
Max. filling capacity [l]
Empty weight [kg] 8
Operation weight [kg] 22
Width [mm]
Height [mm]
Depth [mm]
Water connection
Drain water connection
(1)
Other volta
g
es on re
q
uest
(8)
Flow rate of feed durin
g
refillin
g
.
(2)
1.1 times the current consum
p
tion after full blowdown. Observe tri
pp
in
g
characteristics of circuit breakers.
If necessary, select next higher circuit breaker level
(7)
Maximum water consum
p
tion at 100% demand
p
lus blow down losses.
Water consumption depends on the water quality and options installed.
Technical data SteamKit E (Electrodes)
380 - 415V /3Ph /N /50-60Hz
optional: Standard
220 - 240V / 1,6A
1 x 40 2 x 40
2,8 4,1
21 49
350 420
13,2 35,7
713
tap water of varying qualities
1 to 10 bar, 3/4" external thread
Connection Ø 1 1/4"
700 785
285 400
