POWERMAX65/85 SERIAL COMMUNICATION PROTOCOL
Command Name Register
(Hex)
Description
torch_index 0x0808
0x0809
(Coils)
Reads the torch lead length. Hypertherm controls use this
command to set gas pressure and load the correct cut
charts.
The sample below reads the two coils.
Sample: :010108080002EC0D0A
Response: :010101xxcc
Where xx equals torch length
cc equals LRC (checksum)
Torch lead length is contained in the last 2 bits of the
8-bit response value.
Bit 1 Bit 0 Length
0 0 15 - 25 ft (≤7.6 m)
0 1 35 - 50 ft (≤15 m)
1 0 75 ft (≤23 m)
Responses:
:01010100FD 15 – 25 ft (≤7.6 m)
:01010101FC 35 – 50 ft (≤15 m)
:01010102FB 75 ft (≤23 m)
