Using your Charger: LED Statuses
Your smart EV charger helps to indicate what the charger is doing using the LED bolt on the front and the ring around the front enclosure.
Please note these colours will only show if your charger is set to the “No Effect” LED Mode."
Blue
Solid: Ready to use, no
car plugged in."
Pulsing: Plugged in
and waiting for car to
start charge "
If the Ring is Pulsing
White there is no
internet connection."
Purple
Solid: Set to scheduled
charge but no car
plugged in."
Pulsing: Car plugged in,
waiting to start charging
accordingly to set
schedule.
Green
Solid: Car is charging. "
Reduced bolt size
indicates lower charging
rate due to activation of
ALM safety system or
derating of charger."
Flashing: Waiting on
random delay (page 25)
Orange
Solid: Charger Locked"
Flashing: A Locked
charger is trying to be
used.
Red
The Charger’s safety
system has activated.
The unit is no longer
charging your car."
Check status in the
Hypervolt App and refer
to troubleshooting on
page 27.
Yellow
Solid: Charger inhibited
due to lack of solar
export (Super Eco
Mode Only)"
Pulsing: Insufficient
solar power to charge
vehicle or stopped
from app."
