Mains selection
The PSC2.400 is factory set to operate at a mains voltage of 230Volt. The user is able to change this
setting to 115Volt. Instructions must be followed!
Before changing the mains settings disconnect the unit from the mains and allow all ca-
pacitors to discharge for 10 minutes before handling it.
Update the front plate with the updated information by checking the 115V or 230V setting.
J1: Mains Voltage Input Selection. Connector type: JST-B2P-VH
Pin Function
1,2 Not Connected = 230Vac Mains; Connected = 115Vac Mains
Figure 15
