Hypex Electronics PSC2.400 - Page 5

User manual R5
PSC2.400
- 5 -
Digital version only:
7
AES Though
8
AES 3 Input
9
AES input channel LED’s
Figure
Figure Figure
Figure 2
22
2
Overview of the connections on the back of the PSC2.400
Function
FunctionFunction
Function
1
11
1 J16, Speaker -
2
22
2 J14, Speaker +
3
33
3 J17, Speaker -
4
44
4 J15, Speaker +
* For bridged mode use J14 and J15. Signal on J14 is inverted
Figure
Figure Figure
Figure 3
33
3
Function
FunctionFunction
Function
Jumpers placed is normal function 1
11
1
Jumpers not placed lowers High channel gain with 10dB, this must be corrected in
Hypex Filter Designer under Tools>Options *
* Only available on hardware version PSC2 V3 and up
