Page #27 background imageLoading...
Page #27 background image
5.4 DC Connection
5.4.1 Requirements for the DC Connection
Requirements for the PV modules of a string:
Max. output current
16 A 20 A 23 A
Recommended AC
circuit breaker rating
20 A, type B 25 A, type B 32 A, type B
Type
HPS
-
6000
/
HPS-6000D
HPS
-
65
00
/
HPS-6500D
Max. output current
27.3 A 29.6 A
Recommended AC
circuit breaker rating
40A, type C 40 A, type C
